Русский языкAutomatic die cutting machine operation method and die adjustment method
Nowadays, the most widely used in the die-cutting industry is the fully automatic die-cutting machine, which has brought huge economic benefits to many die-cutting factories and greatly improved the efficiency of die-cutting processing. In the die-cutting process, the operation method and die-adjusting method of the fully automatic die-cutting machine directly have a significant impact on the processing efficiency and the quality of the finished product. Therefore, as a fully-automatic die-cutting operator, it is very important to understand the operation method and the die-adjusting method. important. The following Great Wall takes you to understand the operation method of the automatic die-cutting machine and the detailed explanation of the die adjustment method.
Turn on the power and check the equipment. Test the machine for a few minutes before setting up the mold to ensure that the machine works normally. When the die-cutting machine and the continuous machine punch the product, the knife mold must be straight, otherwise the punched product is easy to be short of material. Remove the template from the machine platform and place it on the workbench, and stick the mold to the tape. The horizontal frame is straight to the upper template. prison.
After installing the template, tighten the right or left screws and increase the pressure so that the gap between the upper and lower templates must be higher than the thickness of the mold plus the PC board. The lower template is fixed on the lower part of the mold with tape on the PC board. Stick the tape on the white paper and stick it on the other side of the PC board that is not taped. The PC board is underneath and the white paper is in the middle; after putting the carbon paper, slowly decrease the pressure, and use the host to tap in and slowly test the pressure until there is a whole knife on the white paper. The mold of the child.
The stamp on the white paper is to facilitate the confirmation of the debugging position when the product is printed. Place the paper under the PC board and use the positioning foam to do the positioning!
After the material is placed, punch out a mold, remove the waste, and check the product. If the product is found to be continuous or has burrs, take out the paper placed under the PC board, and paste the transparent tape on the corresponding defect!
If you find product delamination or over-cutting, you should scrape gently with a blade at the corresponding defective part of the PC board! After the product trial adjustment is completed, the rack material is set to jump distance, etc.! The first mold product that has been rushed out and debugged should be confirmed by the quality control, etc. After the quality control is confirmed, the product can be made! The product should be self-checked frequently until the production is completed!
The above is a detailed introduction about the operation method and mold adjustment method of the automatic die-cutting machine. For more information, supply and knowledge of packaging machinery, please visit the Great Wall website.
