Some basic operating procedures of die-cutting machine

Many people do not know the detailed operation of the die-cutting machine. The detailed operating procedures of the die-cutting machine are listed below:
1. Working hours, focus, strictly abide by the operating procedures, and achieve safe operation.
2. Accurately determine the positioning of the foam strip. Ensure that the die-cut product is the same as the template, and the pattern must meet the typesetting requirements.
Third, the template must be placed on the pallet. Adjust the placement angle according to the production situation.
Fourth, carefully adjust the die-cutting gap. Before adjustment, put the die cutting shaft clearance in a large enough amount. According to the thickness of the cardboard, adjust the adjustment wheels on both sides synchronously, and fine-tune gradually until the cardboard is cut.

5. Before production, check whether the conveyor belt is tight and uniform.
6. Convert automatic or manual die-cutting according to production needs. When turning it on manually, the spirit is highly concentrated. Signal to fellow crew members each time you move. When adjusting the self-travel, pay attention to the length of the table. Prevent the pallet from rushing out of the workbench.
7. Before starting the machine, check whether there are people working inside or outside the machine. Clear all clutter from the workbench. Say hello to fellow crewmembers and prepare to power on.
8. During the operation, all personnel must cooperate carefully and pay attention to safety. Do not touch moving parts with your hands, do not touch buttons at will, and do not stand facing the running direction of the template.
Nine, before production, to pre-trial production. Continuously check multiple products, then fold them into shape, and confirm that they meet the standards before formal production. During the production process, pay attention to observation. Back up, neatly arranged. Fold the semi-finished product into shape and check it every five minutes. If there is a problem, stop and adjust in time.
10. Always check whether the parts are worn or not meet the requirements. Repair or replace in time if there is any problem.

11. Pay attention to machine maintenance and lubrication.
1). The transmission gears are regularly lubricated.
2). The sliding sleeves at both ends of the upper die-cutting shaft are refueled every day;
3). The running bearing shall be overhauled once every six months to one year, and filled with calcium-based butter.
12. Keep the die-cutting shaft clean. The lower axle is often wiped with oil.
Thirteen, the end of production, cut off the power supply.
14. Before starting the machine, wipe the machine first. Keep hands clean. After production, clean around the machine.
The above are the specific operating procedures of the die-cutting machine.
